- Data of inspected Part 1: Material: Inlaid Steel SKH3, Width: 25 mm.
- Crusher (L 506mm, W 100mm, Thickness 16mm).
- Check 5 different positions with Rockwell Hardness Tester, the readings are:
HRC 63.3, 62.6, 63.2, 63.2, and 62.8
- Average value is HRC 63.0
- The results indicate the variation of hardness in different position is small, which represent the quality of heat treatment is stable.
- Data of inspected Part 2: Material: Inlaid Steel SKD6, Width: 40 mm.
- Crusher (L 506mm, W 100mm, Thickness 19mm)
- Check 5 different positions with Rockwell Hardness Tester, the readings are: HRC 60.1, 60.0, 60.2, 60.1, and 60.08
- Average value is HRC 60.1
- The results indicate the variation of hardness in different position is small, which represent the quality of heat treatment is stable.
- Data of inspected Part 1: Material: Inlaid Steel SKH3, Width: 25 mm.
- Crusher (L 506mm, W 100mm, Thickness 16mm)
- Apply 3600kgf tension force on the inspected part, the inlaid steel SKH3 x 25 breaks, while the conjunction surface between two different materials remains firmly adhered. The tension force test is unable to proceed due to the breakage of SKH3 x 25 mm material.
- Data of inspected Part 2: Material: Inlaid Steel SKH6, Width: 40 mm.
- Crusher (L 506mm, W 100mm, Thickness 19mm)
- Apply 2400kgf tension force on the inspected part, the inlaid steel SKH6 x 40 breaks, while the conjunction surface between two different materials remains firmly adhered. The tension force test is unable to proceed due to the breakage of SKH6 x 40 mm material.
- Conclusion of Tension Test: All our inlaid steel Crusher is guaranteed on the adhesive quality.
|
|
|
 |
|
|
 |
|
